Characteristics
- AC/DC
- AC, DC
- Type
- asynchronous
- Voltage
- 220 V, 48 V
- Protection class
- IP65
- Number of poles
- 8-pole
- Other characteristics
- low-voltage
- Power
200 W, 400 W
(0.272 hp, 0.544 hp)- Intensity
Max.: 11 A
Min.: 1.4 A
- Torque
Max.: 3.81 Nm
(2.8101 ft.lb)Min.: 0.637 Nm
(0.4698 ft.lb)- Rotational speed
Max.: 6,000 rpm
(37,699.11 rad.min-1)3,000 rpm
(18,849.56 rad.min-1)Min.: 3,000 rpm
(18,849.56 rad.min-1)- Diameter
60 mm
(2.36 in)- Operating temperature
Max.: 40 °C
(104 °F)Min.: -20 °C
(-4 °F)
