AC/DC

3-phase

Type

EC

Voltage

24 V

Configuration

flat, frameless

Other characteristics

high-torque

Power

100 W
(0.136 hp)

Intensity

Max.:  4,700 mA

Min.:  141 mA

Torque

0.185 Nm
(0.1364 ft.lb)

Rotational speed

Max.:  6,420 rpm
(40,338.05 rad.min-1)

Min.:  0 rpm
(0 rad.min-1)

5,140 rpm
(32,295.57 rad.min-1)

Diameter

42 mm
(1.65 in)

Operating temperature

Max.:  155 °C
(311 °F)

Min.:  -40 °C
(-40 °F)

Description

The EC frameless DT motors are BLDC motor kits with internal-rotor technology. The rotor and stator are delivered separately, without bearings or motor shaft, and are connected only during assembly. The flat design, the high torques, and a lot of space for cable glands allow a high level of integration into your application.
