AC/DC

AC

Type

synchronous

Protection class

IP54

Configuration

permanent magnet

Number of poles

4-pole, 8-pole, 6-pole, 2-pole

Cooling mechanism

air-cooled

Applications

for the chemical industry, for the mining industry

Other characteristics

high-efficiency, energy-saving

Power

30 kW
(40.789 hp)

Min.:  0.75 kW
(1.02 hp)

Max.:  315 kW
(428.281 hp)

Intensity

54.9 A

Min.:  1.72 A

Max.:  549 A

Torque

2 Nm
(1.4751 ft.lb)

Min.:  1.6 Nm
(1.1801 ft.lb)

Max.:  2.8 Nm
(2.0652 ft.lb)

Rotational speed

1,480 rpm
(9,299.11 rad.min-1)

Min.:  705 rpm
(4,429.65 rad.min-1)

Max.:  2,975 rpm
(18,692.48 rad.min-1)

Diameter

280 mm
(11.02 in)

Min.:  80 mm
(3.15 in)

Max.:  355 mm
(13.98 in)

Operating temperature

30 °C
(86 °F)

Min.:  20 °C
(68 °F)

Max.:  60 °C
(140 °F)

Description

This series of motors are mainly used in the industry of petroleum and chemical industry, instead of current asynchronous motors, and can also be used to replace asynchronous motors in other industries.

This series of motor is our high – tech – based, independent innovation and development of efficient and energy-saving products. This product has always maintained a high scientific and technological content, and has always been in the leading position in the industry. The efficiency index is 5 to 8% higher than the average asynchronous motor. It can replace an asynchronous motor with 1-2 power levels (or one larger seat number) larger than it. After replacing the asynchronous motor, a lot of money will be saved in the aspects of active power, reactive power compensation and energy consumption of air conditioning equipment, and the comprehensive electricity saving rate is 10 ~ 40%. The rotor of the motor uses NdFeB permanent magnet excitation mode, structure and magnetic circuit innovation design. The fully enclosed fan is ventilated and cooled. The protection level of the enclosure is above IEC IP54. The insulation level is F. The shape and installation dimension are the same as the asynchronous motor, so it has good interchangeability.

This series of motors are mainly used in the industry of petroleum and chemical industry, instead of current asynchronous motors, and can also be used to replace asynchronous motors in other industries. This series of motor is our high – tech – based, independent innovation and development of efficient and energy-saving products.
