AC/DC

AC

Type

synchronous

Protection class

IP54, IP55

Configuration

permanent magnet, hollow-shaft, stainless steel, small

Number of poles

4-pole, 8-pole, 6-pole, 2-pole

Cooling mechanism

air-cooled

Applications

industrial, for medical equipment, for the textile industry

Other characteristics

high-torque, high-efficiency, low-speed, direct-drive, variable-torque

Power

30 kW
(40.789 hp)

Min.:  0.75 kW
(1.02 hp)

Max.:  315 kW
(428.281 hp)

Intensity

54.9 A

Min.:  1.72 A

Max.:  549 A

Torque

2 Nm
(1.4751 ft.lb)

Min.:  1.6 Nm
(1.1801 ft.lb)

Max.:  2.8 Nm
(2.0652 ft.lb)

Rotational speed

1,480 rpm
(9,299.11 rad.min-1)

Min.:  705 rpm
(4,429.65 rad.min-1)

Max.:  2,975 rpm
(18,692.48 rad.min-1)

Diameter

280 mm
(11.02 in)

Min.:  80 mm
(3.15 in)

Max.:  355 mm
(13.98 in)

Operating temperature

30 °C
(86 °F)

Min.:  20 °C
(68 °F)

Max.:  60 °C
(140 °F)

Description

There is no excitation loss on the rotor of permanent magnet synchronous motor, and there is no friction loss and contact loss between the brush and the slip ring. Therefore, the permanent magnet synchronous motor has high efficiency and its power factor can be designed near 1. AC permanent magnet synchronous motor has the advantages of small volume, light weight, high efficiency and energy saving, good control performance, easy to make low-speed direct drive device, main drive shaft, gear reducer and so on, and the comprehensive energy saving index is 10-40%. After independent innovation, our company has developed a series of high efficiency and energy saving permanent magnet synchronous motor (PMSM) for various industries.
