AC/DC

AC

Type

brushless

Protection class

IP65

Cooling mechanism

air-cooled, forced-ventilated

Other characteristics

high-torque, variable-speed

Power

1.1 kW, 1.61 kW, 2.1 kW
(1.496 hp, 2.189 hp, 2.855 hp)

Intensity

2.4 A, 4.1 A, 4.6 A, 9.9 A, 20 A

Torque

2.4 Nm, 4.4 Nm, 6.8 Nm, 8.6 Nm, 17.3 Nm
(1.7701 ft.lb, 3.2453 ft.lb, 5.0154 ft.lb, 6.343 ft.lb, 12.7598 ft.lb)

Rotational speed

3,000 rpm, 3,500 rpm, 4,500 rpm, 5,000 rpm, 5,300 rpm
(18,849.56 rad.min-1, 21,991.15 rad.min-1, 28,274.33 rad.min-1, 31,415.93 rad.min-1, 33,300.88 rad.min-1)

Description

Applications
• Positioning and actuating drive for drive tasks with or without transmission
• For intermittent operations
• Control drive for continuous operation

Connection cable:
Nominal cross-section of copper conductor 1.5 mm2
Power connector in size 1

BENEFITS
• Extremely efficient
• High standstill torques
• High torques and power density
• Exceptional dynamism
• Extremely low cogging torques during moment pulsations
• Protection class IP65
