AC/DC

DC

Type

brushless

Voltage

60 V

Number of poles

4-pole

Power

Max.:  34 W
(0.046 hp)

Min.:  9 W
(0.012 hp)

Torque

Max.:  0.06 Nm
(0.0443 ft.lb)

Min.:  0.025 Nm
(0.0184 ft.lb)

Rotational speed

12,000 rpm
(75,398.22 rad.min-1)

Diameter

33 mm
(1.3 in)

Description

The EC033A series brushless DC motor is a high torque density model brushless motor in a 33 mm diameter housing. It is offered in 3 motor lengths with continuous torque from 0.025 – 0.06 Nm.

Features:
Speeds up to 12,000 RPM
DC bus voltage up to 60 Vdc
33mm diameter housing
Eight standard windings – Special windings available
4 Pole Rare Earth design
