AC/DC

three-phase

Type

brushless

Voltage

230 V

Protection class

IP69K

Configuration

permanent magnet, stainless steel

Number of poles

4-pole, 2-pole

Applications

high-temperature

Power

94 W, 180 W, 345 W, 740 W
(0.128 hp, 0.245 hp, 0.469 hp, 1.006 hp)

Intensity

0.67 A, 1.4 A, 2.5 A, 3.7 A

Torque

0.3 Nm, 0.58 Nm, 1.1 Nm, 2.35 Nm
(0.2213 ft.lb, 0.4278 ft.lb, 0.8113 ft.lb, 1.7333 ft.lb)

Rotational speed

3,000 rpm
(18,849.56 rad.min-1)

Description

Stainless steel brushless servomotor, AMSS series compliant with EHEDG guidelines on hygiene. 4-pole sinusoidal brushless motor, closed form in stainless steel with smooth finish.
Rotor with NdFeB magnets.
Thermal cutoff.
Class H insulation winding.
IP69K protection in compliance with IEC/EN 60529 standards.
2-Pole resolver feedback.
Roller bearings with reduced backlash and special grease for high temperatures.
